Solid State Relay Card

RL 1335

Highlights

  • 8 Solid State Relay-Outputs
  • Channel-to-Channel Isolation
  • General
    • The relay card RL 1335 was developed for switching's applications in strongly more disturbed, industrial enviroment. The relay card possesses 8 solid state relays with the output data 30 V AC/DC for alternatively 500 mA or 100 mA switching-current. To the protection against high voltages spikes the solid state relays are secured by varistors.
  • Accessory
  • Technical Specifications
    • Outputs: 8x Solid state relays
      -Switch. Voltage: max. 30 V AC/DC
      -Switch. Current:
      -RL 1335/1:
      -RL 1335/2:

      max. 100 mA
      max. 500 mA
      Supply Voltage: +5 V, max. 0,2 A
      Connector: DB25-male
      EMC: EMC-conform to 2004/108/EG
      Operating Temperature: 0 - 50 °C
      Storage Temperature: -25 to + 85 °C
      Dimensions: 104 x 79 mm
